Festo VUVG M7 5/2 Solenoid/Spring Inline Pneumatic Solenoid Valve

Function: 5/2

Mounting Style: Inline

Solenoid Fitted: Yes

Minimum Operating Temperature: -5°C

Maximum Operating Pressure: 7bar

Maximum Flow Rate: 340L/min

Thread Standard: Metric

Connection Port Thread: M7

Solenoid Voltage: 24V dc

Thread Size: M7

Number of Ports: 5

Body Material: Aluminium Alloy

Manufacturer Series: VUVG Actuation Type: Solenoid/Spring Minimum Operating Pressure: 2.5bar Solenoid Power Consumption: 0.8W Maximum Operating Temperature: +50°C Number of Positions: 2

This is VUVG M7 5/2 Solenoid/Spring Inline Pneumatic Solenoid Valve manufactured by Festo. The manufacturer part number is VUVG-LK10-M52-AT-M7-1H2L-S. It performs basic function of 5/2. The product is available in inline style. It includes a fitted solenoid yes . Whereas, the minimum operating temperature of the product is -5°c. It features 7bar maximum operating pressure. The product provides up to 340l/min maximum flow rate. The threaded is a metric standard. It also features m7 connection port thread. It has 24v dc solenoid voltage . It has a typical thread size of m7. This product features 5 number of ports. The product’s body is nicely designed from aluminium alloy materials. The product has a vuvg manufacturer series. It also features solenoid/spring actuation. It has a minimum 2.5bar operating pressure . Its solenoid power consumption is approximately 0.8w . It has a maximum operating temperature of +50°c. The product carries possible position value of 2.
