Broadcom HDSP-H151 7-Segment LED Display, CA Red 16 mcd RH DP 14.2mm

Dominant Wavelength: 637 nm

Forward Current: 40mA

Common Connection: Anode

Character Width: 7.8mm

External Depth: 17mm

Forward Voltage: 1.8 V

Luminous Intensity: 16 mcd

Maximum Operating Temperature: +100°C

Colour of Face: Grey

Operating Temperature Range: -20 → +100°C

Character Height: 14.2mm

Number of Segments: 7

External Dimensions: 12.573 x 17.02 x 8mm Display Type: 7-Segment Mounting Type: Through Hole Number of Characters: 1 Minimum Operating Temperature: -20°C LED Colours: Red Decimal Orientation: Right Side External Height: 8mm External Width: 12.6mm

This is 7-Segment LED Display CA Red 16 mcd RH DP 14.2mm manufactured by Broadcom. The manufacturer part number is HDSP-H151. It has a dominant wavelength of 637 nm. It features 40ma forward current. It has a common anode connection . In addition, it has about 7.8mm character width . It has an external depth of 17mm. The forward voltage is 1.8 v. It has 16 mcd of luminous intensity. It has a maximum operating temperature of +100°c. It is created with a grey colour face . The product has -20 → +100°c of operating temperature range. It has a standard 14.2mm character in height . It includes 7 segments . Features 12.573 x 17.02 x 8mm external caliber. It features a remarkable 7-segment display. The product is available in through hole configuration. Consists of 1 characters. Whereas, the minimum operating temperature of the product is -20°c. The LED has a classic red colours. Its decimal orientation is to the right side . While its external height is 8mm. The product is 12.6mm wide.
