Allegro Microsystems A3984SLPTR-T, Stepper Motor Driver IC, 35 V 2A, TSSOP 24-Pin

Dimensions: 7.8 x 4.4 x 1.05mm

Mounting Type: Surface Mount

Minimum Operating Supply Voltage: 3 V

Maximum Collector Emitter Voltage: 35 V

Maximum IGBT Collector Current: 2A

Height: 1.05mm

Width: 4.4mm

Length: 7.8mm

Package Type: TSSOP

Minimum Operating Temperature: -20 °C

Output Configuration: Bipolar

Motor Type: Stepper

Maximum Operating Temperature: +85 °C Pin Count: 24 Maximum Operating Supply Voltage: 5.5 V Function: Driver – Fully Integrated, Control and Power Stage Base Part Number: A3984 Detailed Description: Bipolar Motor Driver DMOS Logic 24-TSSOP-EP Mounting Type: Surface Mount Current – Output: 2A Voltage – Load: 8V ~ 35V Supplier Device Package: 24-TSSOP-EP Packaging: Cut Tape (CT) Applications: General Purpose Operating Temperature: -20°C ~ 150°C (TJ) Step Resolution: 1, 1/2, 1/4, 1/16 Voltage – Supply: 3V ~ 5.5V Customer Reference: Package / Case: 24-TSSOP (0.173″, 4.40mm Width) Exposed Pad Interface: Logic Output Configuration: Half Bridge (4) Technology: DMOS Motor Type – Stepper: Bipolar Manufacturer: Allegro MicroSystems

This is Stepper Motor Driver IC 35 V 2A TSSOP 24-Pin manufactured by Allegro Microsystems. The manufacturer part number is A3984SLPTR-T. The given dimensions of the product include 7.8 x 4.4 x 1.05mm. The product is available in surface mount configuration. While its minimum operating supply voltage is 3 v. Whereas features a 35 v of collector emitter voltage (max). It has a maximum 2a IGBT collector current . In addition, the height is 1.05mm. Furthermore, the product is 4.4mm wide. Its accurate length is 7.8mm. The package is a sort of tssop. Whereas, the minimum operating temperature of the product is -20 °c. It boasts bipolar output configuration. This high-efficiency motor is a stepper. It has a maximum operating temperature of +85 °c. It contains 24 pins. It has 5.5 v maximum operating supply voltage. It performs basic function of driver – fully integrated, control and power stage. Base Part Number: a3984. It features bipolar motor driver dmos logic 24-tssop-ep. While, the output current includes 2a. The given load voltage is 8v ~ 35v. 24-tssop-ep is the supplier device package value. In addition, cut tape (ct) is the available packaging type of the product. The product is widely employed in general purpose. The product has -20°c ~ 150°c (tj) operating temperature range. The product features 1, 1/2, 1/4, 1/16 step resolution. It has optimum voltage supply of 3v ~ 5.5v. Moreover, the product comes in 24-tssop (0.173″, 4.40mm width) exposed pad. A bespoke product is logic interface. It boasts half bridge (4) output configuration. This product use dmos technology. The stepper motor has a bipolar motor. The allegro microsystems’s product offers user-desired applications.
