TXC CORPORATION 7C-24.576MBB-T

Ratings: –

HTSUS: 8542.39.0001

RoHS Status: RoHS Compliant

Frequency Stability: ±50ppm

Operating Temperature: -10°C ~ 70°C

Package / Case: 4-SMD, No Lead

Type: XO (Standard)

Function: Enable/Disable

Absolute Pull Range (APR): –

Height – Seated (Max): 0.055″ (1.40mm)

REACH Status: REACH Unaffected

edacadModel: 7C-24.576MBB-T Models

Current – Supply (Max): 30mA edacadModelUrl: /en/models/2118887 Size / Dimension: 0.197″ L x 0.126″ W (5.00mm x 3.20mm) Output: CMOS standardLeadTime: 46 Weeks Moisture Sensitivity Level (MSL): 1 (Unlimited) Mounting Type: Surface Mount Series: 7C Base Resonator: Crystal Current – Supply (Disable) (Max): – Packaging: Tape & Reel (TR) Frequency: 24.576 MHz Voltage – Supply: 3.3V ECCN: EAR99

The TXC CORPORATION 7C-24.576MBB-T is a highly precise and stable oscillator operating at a frequency of 24.576 MHz. It belongs to the XO (Crystal Oscillator) category, specifically designed to provide a standard clock signal for electronic devices. This oscillator uses Complementary Metal-Oxide-Semiconductor (CMOS) technology, known for its low power consumption and high noise immunity, making it suitable for various digital applications.

• Electrical Specifications

Operating at a voltage of 3.3V, the 7C-24.576MBB-T is built to be energy efficient, which is crucial for battery-powered and portable devices. The enable/disable function provides additional power management capabilities, allowing the oscillator to be turned off when not in use, further conserving energy.

Exceptional Benefits of Buying the TXC CORPORATION 7C-24.576MBB-T, Surface Mount Oscillator Crystal

• Ensures reliable clocking for critical digital circuits.
• Ideal for battery-operated devices.
• Offers power-saving features for energy-efficient operation.
• Allows for more efficient use of PCB space.
• Ensures compatibility with various digital circuits.

Physical Characteristics

This oscillator comes in a 4-SMD (Surface Mount Device) package with no lead, ensuring a compact footprint and ease of integration into various electronic assemblies. The small size and SMD design allow for efficient use of board space and compatibility with modern PCB (Printed Circuit Board) manufacturing processes.

Typical Applications of the TXC CORPORATION 7C-24.576MBB-T, Crystal Oscillator

The TXC CORPORATION 7C-24.576MBB-T oscillator finds its application in various fields due to its versatility and performance. Some of the critical applications include:

• Smartphones, tablets, and gaming consoles.
• Utilised in network equipment and base stations.
• For timing in automation systems and industrial controllers.
• In electronic control units and infotainment systems.
• As a clock source in microprocessors and peripheral devices.
