Teledyne LeCroy T3PS43203P

Digital/Analogue: Digital

Output Connector: Ext I/O, LAN, RS-232, Type A USB

Output Current: 0 → 3A

Number of Outputs: 4

Maximum Temperature: +40°C

Series: T3PS

Bench Power Supply Type: Programmable Power Supply

Model Number: T3PS43203P

Output Voltage: 0 → 32V

Supply Voltage: 230V ac

Minimum Temperature: 0°C

Number of Displays: 1

Power Rating: 0 → 50W Type: Programmable Linear Power Supply HTSUS: 8504.40.9580 RoHS Status: ROHS3 Compliant Power (Watts): 212W Moisture Sensitivity Level (MSL): 1 (Unlimited) Type: Bench (AC to DC) Current Regulation – Line: 0.2% + 3mA title: T3PS43203P Current – Output: 0 ~ 3A, 0 ~ 3A, 0 ~ 1A, 0 ~ 1A Manufacturer: Teledyne LeCroy Accuracy – Voltmeter; Ammeter: – Size / Dimension: – Ripple: 1mV rms Number of Characters: – Current Regulation – Load: 0.2% + 3mA standardLeadTime: 19 Weeks Voltage Regulation – Load: 0.01% + 3mV Display Type: LCD Features: Linear, Programmable Series: – Voltage – Output: 0 ~ 32VDC, 0 ~ 32VDC, 0 ~ 15VDC, 0 ~ 5VDC Packaging: Box Voltage Regulation – Line: 0.01% + 3mV Voltage – Supply: – Base Product Number: T3PS43203 Number of Outputs: 4 ECCN: 3A992A

This ismanufactured by Teledyne LeCroy. The manufacturer part number is T3PS43203P. It is digital . Features a versatile ext i/o, lan, rs-232, type a usb output connector. It carries 0 → 3a output current. Additionally, the product is supplied with 4 outputs. The product has +40°c maximum temperature. The product t3ps, is a highly preferred choice for users. Its bench power supply is of programmable power supply type . It has a model number t3ps43203p. Features a 0 → 32v output voltage. Features 230v ac supply voltage. While its minimum temperature is 0°c. It includes 1 display(s) . Feature 0 → 50w of power rating. It comes in programmable linear power supply configuration. It is assigned with possible HTSUS value of 8504.40.9580. The product is rohs3 compliant. The product features power and watts of 212w. Its typical moisture sensitivity level is 1 (unlimited). It comes in bench (ac to dc) configuration. Current regulation – line of 0.2% + 3ma. While, the output current includes 0 ~ 3a, 0 ~ 3a, 0 ~ 1a, 0 ~ 1a. The teledyne lecroy’s product offers user-desired applications. Ripple – 1mv rms. While load current regulation is 0.2% + 3ma. It has a long 19 weeks standard lead time. While the load voltage regulation of 0.01% + 3mv. It features a remarkable lcd display. The splendid features of the product include linear, programmable. Furthermore, the output voltage is 0 ~ 32vdc, 0 ~ 32vdc, 0 ~ 15vdc, 0 ~ 5vdc. In addition, box is the available packaging type of the product. The product allows 0.01% + 3mv of line voltage regulation. Moreover, it corresponds to t3ps43203, a base product number of the product. The product is designated with the 3a992a code number.
