TE Connectivity 4PDT Non-Latching Relay DIN Rail, 24V ac Coil, 6 A

Maximum Operating Temperature: +70°C

Mounting Type: DIN Rail

Coil Power: 1W

Series: PT

Latching: No

Coil Voltage: 24V ac

Length: 73.5mm

Height: 58mm

Switching Current: 6A

Application: Interface

Depth: 27mm

Minimum Operating Temperature: -40°C

Contact Configuration: 4PDT Maximum Switching Power AC: 1.5 kVA Contact Material: Gold Plated Number of Poles: 4 Terminal Type: Screw Coil Resistance: 192Ω

This is 4PDT Non-Latching Relay DIN Rail 24V ac Coil 6 A manufactured by TE Connectivity. The manufacturer part number is PT5S8RC4 3-1415075-1. It has a maximum operating temperature of +70°c. The product is available in din rail configuration. Robust coil power of 1w. The product pt, is a highly preferred choice for users. Latching Options – no. The coil voltage of the product is 24v ac. Its accurate length is 73.5mm. In addition, the height is 58mm. It is integrated with 6a switching current. Applications Information involves interface. The product comes in 27mm depth. Whereas, the minimum operating temperature of the product is -40°c. The contact is equipped with 4pdt configuration. It also features an AC switching power of 1.5 kva. The product is made from sturdy gold plated materials. It has equipped with 4 poles. The terminal is a screw type. It holds up to 192ω coil resistance.
