Dimensions: 21.84 x 14.99 x 6.99mm
Mounting Type: Through Hole
Height: 6.99mm
Width: 14.99mm
Length: 21.84mm
Package Type: SNAPHAT
Minimum Operating Temperature: 0 °C
IC Type: Battery Backup IC
Maximum Operating Temperature: +70 °C
Pin Count: 4
Capacity: 120mAh
Voltage – Rated: 2.8 V
RoHS Status: ROHS3 Compliant Operating Temperature: 0°C ~ 70°C (TA) Type: Battery and Crystal HTSUS: 8504.40.7018 title: M4T32-BR12SH1 REACH Status: REACH UnaffectedManufacturer: STMicroelectronics Moisture Sensitivity Level (MSL): 1 (Unlimited) standardLeadTime: 24 Weeks Load Capacitance: 12.5 pF Series: Timekeeper®, Snaphat® Packaging: Tube Frequency: 32.768 kHz Battery Chemistry: Lithium Base Product Number: M4T32 ECCN: EAR99
The STMicroelectronics M4T32-BR12SH1 is a high-performance battery charger IC that’s widely trusted for timekeeping applications in embedded systems. Designed with a compact 4-pin SNAPHAT form factor, this module is engineered for compatibility with ST’s Timekeeper RAM and Supervisor chips. Its reliable 48mAh lithium coin cell and integrated crystal make it an ideal solution for maintaining real-time clock (RTC) data during power outages. UK customers looking for a dependable and maintenance-free backup battery solution will find this product an excellent fit for critical electronics and industrial systems.
Unmatched Advantages of Buying the STMicroelectronics Battery Charger IC 4-Pin
- Provides uninterrupted timekeeping during power loss.
- Simplifies design with modular, plug-in SNAPHAT construction.
- Reduces servicing and battery replacement needs.
- Long shelf-life and high energy efficiency.
Standout Features of Product
- SNAPHAT top with lithium coin cell and 32.768kHz crystal.
- 4-pin interface for easy mounting.
- Designed for ST Timekeeper SRAMs and controllers.
- RoHS-compliant and lead-free.
Application Potential of the STMicroelectronics Battery Charger
- Embedded systems and industrial controllers
- Data loggers and metering devices
- Telecommunication and networking equipment
- Real-time clock (RTC) modules in consumer electronics
- Backup systems in mission-critical operations
