MERCURY VM53S3-25.000-2.5/-30+75, Voltage Controlled Oscillator, 25 MHz 2.75 → 5 V, 4-Pin SMD 5×3.2mm

Dimensions: 5 x 3.2 x 1.5mm

Load Capacitance: 15pF

Oscillator Type: TCXO

Height: 1.5mm

Frequency Stability: ±2.5ppm

Output Level: Clipped Sinewave

Package Type: VM53S

Output Frequency: 25MHz

Minimum Operating Temperature: -30°C

Maximum Supply Voltage: 5V

Maximum Operating Temperature: 75°C

This is Voltage Controlled Oscillator 25 MHz 2.75 → 5 V 4-Pin SMD 5×3.2mm manufactured by MERCURY. The manufacturer part number is VM53S3-25.000-2.5/-30+75. The given dimensions of the product include 5 x 3.2 x 1.5mm. It features 15pf load capacitance. The product is a tcxo type of oscillator. In addition, the height is 1.5mm. It also carries ±2.5ppm of stable frequency value. Its output level is clipped sinewave . The package is a sort of vm53s. This product has an output frequency range of 25mhz. Whereas, the minimum operating temperature of the product is -30°c. The product requires a maximum 5v supply voltage . It has a maximum operating temperature of 75°c.
