Fairchild FDB075N15A_F085 N-channel MOSFET, 110 A, 150 V PowerTrench, 3-Pin TO-263

Category: Power MOSFET

Dimensions: 10.67 x 9.65 x 4.83mm

Maximum Continuous Drain Current: 110 A

Transistor Material: Si

Width: 9.65mm

Transistor Configuration: Single

Maximum Drain Source Voltage: 150 V

Package Type: TO-263

Number of Elements per Chip: 1

Minimum Gate Threshold Voltage: 2V

Maximum Operating Temperature: +175 °C

Typical Gate Charge @ Vgs: 80 nC @ 10 V

Channel Type: N Typical Input Capacitance @ Vds: 5595 pF @ 75 V Length: 10.67mm Pin Count: 3 Typical Turn-Off Delay Time: 76 ns Mounting Type: Surface Mount Channel Mode: Enhancement Maximum Power Dissipation: 333 W Series: PowerTrench Maximum Gate Source Voltage: ±20 V Height: 4.83mm Typical Turn-On Delay Time: 33 ns Minimum Operating Temperature: -55 °C Maximum Drain Source Resistance: 20 mΩ

This is Fairchild N-channel MOSFET 110 A 150 V PowerTrench 3-Pin TO-263 manufactured by Fairchild Semiconductor. The manufacturer part number is FDB075N15A_F085. It is of power mosfet category . The given dimensions of the product include 10.67 x 9.65 x 4.83mm. While 110 a of maximum continuous drain current. The transistor is manufactured from highly durable si material. Furthermore, the product is 9.65mm wide. The product offers single transistor configuration. It has a maximum of 150 v drain source voltage. The package is a sort of to-263. It consists of 1 elements per chip. Whereas its minimum gate threshold voltage includes 2v. It has a maximum operating temperature of +175 °c. With a typical gate charge at Vgs includes 80 nc @ 10 v. The product is available in [Cannel Type] channel. Its typical input capacitance @ Vds is 5595 pf @ 75 v . Its accurate length is 10.67mm. It contains 3 pins. Whereas, its typical turn-off delay time is about 76 ns . The product is available in surface mount configuration. The product carries enhancement channel mode. Provides up to 333 w maximum power dissipation. The product powertrench, is a highly preferred choice for users. It features a maximum gate source voltage of ±20 v. In addition, the height is 4.83mm. In addition, it has a typical 33 ns turn-on delay time . Whereas, the minimum operating temperature of the product is -55 °c. It provides up to 20 mω maximum drain source resistance.
