Eaton XV3550-2R7307-R

Diameter: 35mm

Dimensions: 35 x 50mm

Lead Diameter: 1.5mm

Mounting Type: Through Hole

Minimum Operating Temperature: -40°C

Capacitor Family: Electric Double Layer

Equivalent Series Resistance: 6mΩ

Height: 50mm

Capacitance: 300F

Depth: 50mm

Voltage: 2.7V dc

Product Diameter: 4mm

Lifetime: 1500h Lead Pitch: 22.5mm Maximum Operating Temperature: +65°C Tolerance: -5 → +10% Terminal Type: Through Hole Manufacturer Standard Lead Time: 13 Weeks Detailed Description: 300F (EDLC) Supercapacitor 2.7V Radial, Can – Snap-In 4.5 mOhm 1500 Hrs @ 65°C Voltage – Rated: 2.7V ESR (Equivalent Series Resistance): 4.5 mOhm Capacitance: 300F Operating Temperature: -40°C ~ 65°C Package / Case: Radial, Can – Snap-In Tolerance: -5%, +10% Height – Seated (Max): 2.047″ (52.00mm) Standard Package: 20 Manufacturer: Eaton Size / Dimension: 1.378″ Dia (35.00mm) Termination: PC Pins Moisture Sensitivity Level (MSL): 1 (Unlimited) Mounting Type: Through Hole Series: PowerStor XV Packaging: Bulk Lifetime @ Temp.: 1500 Hrs @ 65°C Lead Spacing: 0.886″ (22.50mm) Other Names: 283-4210 XV35502R7307R

This ismanufactured by Eaton. The manufacturer part number is XV3550-2R7307-R. Its diameter is 35mm. The given dimensions of the product include 35 x 50mm. Furthermore, the lead has 1.5mm diameter. The product is available in through hole configuration. Whereas, the minimum operating temperature of the product is -40°c. It is from electric double layer capacitor family . It has 6mω equivalent series resistance. In addition, the height is 50mm. It provides a 300f of capacitance value. The product comes in 50mm depth. It carries a 2.7v dc of voltage. Whereas, the product’s diameter is almost 4mm . It provides a long-lasting service for a period of 1500h. The lead features 22.5mm pitch. It has a maximum operating temperature of +65°c. It features -5 → +10% of tolerance value. The terminal is a through hole type. It has typical 13 weeks of manufacturer standard lead time. It features 300f (edlc) supercapacitor 2.7v radial, can – snap-in 4.5 mohm 1500 hrs @ 65°c. It also exhibits voltage rating of 2.7v. It carries ESR (Equivalent Series Resistance) of 4.5 mohm. The product has -40°c ~ 65°c operating temperature range. Moreover, the product comes in radial, can – snap-in. It features -5%, +10% of tolerance value. It has the maximum seated height of 2.047″ (52.00mm). It is available in the standard package of 20. The eaton’s product offers user-desired applications. The product’s diameters include 1.378″ dia (35.00mm). The product features pc pins termination style. Its typical moisture sensitivity level is 1 (unlimited). The product powerstor xv, is a highly preferred choice for users. In addition, bulk is the available packaging type of the product. This product offers longer life span for 1500 hrs @ 65°c. It is assigned with 0.886″ (22.50mm) of lead spacing. Alternative Names include 283-4210 xv35502r7307r.
