Broadcom 5082-7610 7-Segment LED Display, CA Red 800 mcd LH DP 7.62mm

External Dimensions: 19.1 x 10.2 x 4.6mm

Display Type: 7-Segment

Colour of Face: Grey

Mounting Type: Through Hole

Operating Temperature Range: -40 → +100°C

Common Connection: Anode

Character Dimensions: 7.62 x 5.18mm

Number of Segments: 7

Character Height: 7.62mm

External Depth: 4.6mm

Character Width: 5.18mm

Luminous Intensity: 800 mcd

Number of Characters: 1 Minimum Operating Temperature: -40°C LED Colours: Red Decimal Orientation: Left Side External Height: 19.1mm External Width: 10.2mm Maximum Operating Temperature: +100°C

This is 7-Segment LED Display CA Red 800 mcd LH DP 7.62mm manufactured by Broadcom. The manufacturer part number is 5082-7610. Features 19.1 x 10.2 x 4.6mm external caliber. It features a remarkable 7-segment display. It is created with a grey colour face . The product is available in through hole configuration. The product has -40 → +100°c of operating temperature range. It has a common anode connection . Its character dimensions are about 7.62 x 5.18mm . It includes 7 segments . It has a standard 7.62mm character in height . It has an external depth of 4.6mm. In addition, it has about 5.18mm character width . It has 800 mcd of luminous intensity. Consists of 1 characters. Whereas, the minimum operating temperature of the product is -40°c. The LED has a classic red colours. Its decimal orientation is to the left side . While its external height is 19.1mm. The product is 10.2mm wide. It has a maximum operating temperature of +100°c.
