1:1 Through Hole Telecom Transformer, 19μH, 1.1Ω

Primary DC Resistance: 1.1Ω

Dimensions: 13 x 13 x 15mm

Mounting Type: Through Hole

Leakage Inductance: 19µH

Length: 13mm

Maximum Operating Frequency: 1MHz

Width: 13mm

Depth: 15mm

Minimum Operating Frequency: 3kHz

Turns Ratio: 1:1

Primary Inductance: 19µH

Secondary DC Resistance: 0.9Ω

This is 1:1 Through Hole Telecom Transformer 19μH 1.1Ω manufactured by OEP. The manufacturer part number is PT4. Additionally, it has 1.1ω primary DC resistance . The given dimensions of the product include 13 x 13 x 15mm. The product is available in through hole configuration. It has about 19µh leakage inductance . Its accurate length is 13mm. It carries 1mhz of maximum operating frequency. Furthermore, the product is 13mm wide. The product comes in 15mm depth. It has a minimum 3khz operating frequency . It has 1:1 turns ratio . Additionally, it has 19µh primary inductance . It has about 0.9ω secondary DC resistance .
