1:1 Surface Mount Telecom Transformer, 3.6h, 111Ω

Primary DC Resistance: 111Ω

Maximum Temperature: +85°C

Dimensions: 9 x 7.3 x 14.2mm

Mounting Type: Surface Mount

Leakage Inductance: 4100µH

Minimum Temperature: -10°C

Length: 9mm

Maximum Operating Frequency: 4kHz

Width: 7.3mm

Depth: 14.2mm

Minimum Operating Frequency: 200Hz

Turns Ratio: 1:1

Primary Inductance: 3.6H Termination Type: Solder Insertion Loss: 4dB Secondary DC Resistance: 111Ω

This is 1:1 Surface Mount Telecom Transformer 3.6h 111Ω manufactured by OEP. The manufacturer part number is OEP8000. Additionally, it has 111ω primary DC resistance . The product has +85°c maximum temperature. The given dimensions of the product include 9 x 7.3 x 14.2mm. The product is available in surface mount configuration. It has about 4100µh leakage inductance . While its minimum temperature is -10°c. Its accurate length is 9mm. It carries 4khz of maximum operating frequency. Furthermore, the product is 7.3mm wide. The product comes in 14.2mm depth. It has a minimum 200hz operating frequency . It has 1:1 turns ratio . Additionally, it has 3.6h primary inductance . The product is designed with a solder termination. Allows 4db of insertion loss. It has about 111ω secondary DC resistance .
